Appendix A
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 161
List of Parameters
The abbreviations used in the parameter lists have the
following meaning:
Quick Configuration (Basis)
When first switching on or after activating the default
settings (S4.2 = 1), you are guided step by step through the
provided parameters by the quick start assistant. The defined
values are confirmed with the OK button or they can be
changed to suit your application and the motor data.
The quick start assistant can be switched off in the first
parameter (P1.1) by entering a zero (access to all
parameters).
In parameter P1.2, you can switch to the specified
application setting with the quick start assistant (see table on
Page 40).
The quick start assistant ends this first cycle by automatically
switching to frequency display (M1.1 = 0.00 Hz).
By selecting the parameter level (PAR) again, besides the
selected parameters for the quick configuration, the system
parameters (S) are also shown in other cycles.
Quick Start Parameter Guide (Full parameter guide begins on Page 164)
PNU Parameter number
ID Identification number of the parameter
RUN Access to the parameters during operation (RUN):
= Modification permissible,
X = Modification only possible in STOP
ro/rw Parameter read and write permissions via a fieldbus
connection (BUS):
ro = read only
rw = read and write
FS Factory setting of the parameters
User setting User setting of the parameters
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P1.1 115 rw Quick start parameters 0 = All parameters (disable)
1 = Only quick configuration parameters
(enable)
67 1
P1.2 540 X rw Application 0 = Basic
1 = Pump drive
2 = Fan drive
3 = High load
67 0
P1.3 1472 X rw Country specific default
settings
0 = EU
1 = NA
67 1
P6.1 125 rw Primary remote control source 1 = Control signal terminals (I/O)
2 = Control unit (KEYPAD)
3 = Fieldbus (BUS)
82 0
P6.2 117 rw Primary remote speed reference 0 = Fixed frequency (FF0)
1 = Control unit (KEYPAD)
2 = Fieldbus (BUS)
3 = AI1 (analog setpoint 1)
4 = AI2 (analog setpoint 2)
5 = Motor potentiometer
82 3
P6.3 101 X rw Minimum frequency 0.00–P6.4 Hz 83 0.00
P6.4 102 X rw Maximum frequency P6.3–320.00 Hz 83 60.00
P6.5 103 X rw Primary acceleration time (acc1) 0.1–3000s 83 3.0
P6.6 104 X rw Primary deceleration time (dec1) 0.1–3000s 83 3.0
P6.7 505 X rw
Start function 0 = Acceleration time (ramp)
1 = Flying restart circuit
84 0
P6.8 506
X rw Stop function 0 = Fee coasting
1 = Deceleration time (ramp)
84 0
