Anhang/Appendix
48
01/11 MN03402003Z-DE/EN
PKZM0-0,4/XTPRP40BC1
Bereich/Range 0.25 - 0.4 A (NM - HM)
Umgebungstemperatur/Ambient temperature
20 °C
Auslöseklasse/Tripping class
10 A
Toleranzbereich/Tolerance range
g 20 %
Einstellung/
Setting
Auslösezeit/Tripping time t [s]
NM HM
3-phase a 2-phase c 3-phase b 2-phase d
3 x I 19 12.5 17.5 10.8
7.2 x I 4.2 3.2 3.8 2.9
