Patient Monitor User Manual Product Specification
- 279 -
Dimensions (W × D ×
H)
38 mm × 37 mm × 34 mm (1.49” × 1.45” ×1.34”)
Weight ≤ 25 g (cable excluded)
According to the degree
of protection against
harmful ingress of
water
IP44
Mechanical robustness Withstand repeated 1.8 m drops on a hard surface.
Complies with requirements for shock and vibration for professional
transportation according to EN ISO 80601-2-55:2011 and
requirements for road ambulances according to EN1789:2007
(clause 6.4).
Recovery time after
defibrillator test
Unaffected
Drift of measurement
accuracy
No drift
Surface temperature (at
ambient temp. 23
°C)
Max 46
°C / 115 ℉
Airway adapters
Disposable adult/pediatric:
- Adds less than 6 ml deadspace
- Pressure drop less than 0.3 cm H
2
O @ 30 LPM
Disposable infant:
- Adds less than 1 ml deadspace
- Pressure drop less than 1.3 cm H
2
O @ 10 LPM
(Infant Airway Adapter recommended for Tracheal Tube ID size ≤ 4
mm)
Breath detection Adaptive threshold, minimum 1 vol% change in CO
2
concentration.
Respiration rate
0 to 150
± 1 bpm. The respiration rate I displayed after three
breaths and the average value is updated every breath. (Measured at
I/E ratio 1:1 using breath simulator according to EN ISO
80601-2-55 fig. 201.101.)
