EINHELL TE-JS 100 User Manual

GB
- 20 -
4. Technical data
Mains voltage: ............................... 230 V ~ 50 Hz
Power consumption: .................................. 750 W
Stroke speed: ............................800 - 3,000 min
-1
Stroke height: ........................................... 23 mm
Cutting depth, wood: .............................. 100 mm
Cutting depth, plastic: .............................. 12 mm
Cutting depth, iron/Aluminium: ................. 10 mm
Miter cut: ........................ up to 45° (left and right)
Protection class: ...........................................II /
쓑
Weight: .......................................................2.4 kg
Danger !
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level ..................... 87,7 dB(A)
K
pA
uncertainty .............................................3 dB
L
WA
sound power level ....................... 98,7 dB(A)
K
WA
uncertainty .............................................3 dB
Wear ear-muff s.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Cutting wood
Vibration emission value a
h
= 7,423 m/s
2
K uncertainty = 1.5 m/s
2
Cutting sheet metal
Vibration emission value a
h
= 8,512 m/s
2
K uncertainty = 1.5 m/s
2
The specifi ed vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specifi ed value
in exceptional circumstances.
The specifi ed vibration value can be used to
compare the equipment with other electric power
tools.
The specifi ed vibration value can be used for initi-
al assessment of a harmful eff ect.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution! Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Always pull the power plug before making
Warning! adjustments to the equipment.
5.1 Safety guard (Fig. 2/Item 15)
•
The safety guard (15) protects the user from
accidentally touching the saw blade (12) but
still gives you an unobstructed view of the
cutting area.
•
The safety guard (15) must always be fitted
and in position before starting any sawing
work.
•
The safety guard (15) can be pulled up as
shown in Fig. 2.
Anleitung_TE_JS_100_SPK9.indb 20Anleitung_TE_JS_100_SPK9.indb 20 17.05.2017 11:45:1217.05.2017 11:45:12

EINHELL TE-JS 100 Specifications

General

Stroke height	23 mm
No-load stroke rate	3000 spm
Input power	- W
Output power	750 W
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz
Cutting depth in wood	100 mm
Cutting depth in non-alloyed steel	10 mm
Soft grip	Yes
Product color	Black, Red
Bevel capacity (max)	45 °

Weight and Dimensions

Depth	415 mm
Height	310 mm
Weight	2300 g
