FB1200 Flow Computer Quick Start Guide

D301786X012

November 2023

Required Tools

Certain tools and

equipment

are required for installing and servicing the flow

computer.

Table 1: Required Tools

Tool

Use

Torque wrench

For bolting/mounting the flow computer

2.5 mm hexagonal wrench

For manipulating rotation set screw

3 mm hexagonal wrench

For screw for M4 x 0.7 end cap retaining clamp (ATEX

required)

9/16 in hexagonal wrench

For installing/removing ¾ in NPT conduit plugs

1 1/16 in combination wrench

For installing/removing ¾ in NPT to M20 thread reducer

(ATEX required)

#1 Phillips-head screwdriver

For screws on HMI module

#2 Phillips-head screwdriver

For screws on other modules and boards

1/8 inch flat-head screwdriver

For 5.08 mm pitch terminal block connections

1/16-inch flat head screwdriver

For 3.81 mm pitch terminal block connections

Laptop PC running Field Tools

with FBxConnect configuration

software

For software configuration
