20100205 14-10 A01F4EL
IR SENSOR CBA
JUNCTION CBA
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C113 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C115 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
DIODES
D104 LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
D105 LED L-53HT NP4Z000L53HT
RESISTORS
R123 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R124 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R126 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R127 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R128 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
MISCELLANEOUS
CL101 WIRE ASSEMBLY 8P 8PIN/170MM WX1A94F0-001
CL103 WIRE ASSEMBLY 4P 4PIN/250MM WX1A94F0-003
RS102 SENSOR REMOTE RECEIVER KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN101 242 SERIES CONNECTOR TUC-P08X-B1 WHT
ST
JCTUB08TG002
