Reference Manual MAS2600: Maintenance and Troubleshooting
RM 6000-01-001-24 August 2023
50
8 Measure sensor bridge resistance with
sensor cable unconnected between:
If the measured resistance is less than 1
K Ohm or greater than 50 K Ohm the
sensor is considered defect.
Terminal 7 to terminal 8. K Ohm
Terminal 7 to terminal 9. K Ohm
Terminal 7 to terminal 10. K Ohm
Terminal 8 to terminal 9. K Ohm
Terminal 8 to terminal 10. K Ohm
Terminal 9 to terminal 10. K Ohm
9 Visual inspect the transmitter for:
- Damages on the cable
- Sharp bends on the cable
- Moisture/liquids in the breather tube
- Damages on the diaphragm
10 Comments
Step Result Unit Limits
