06-11
Ensure that the roof bonnet is securely
fastened before you drive off.
To open the roof bonnet
Before opening the bonnet, ensure that the area
above the opening of the bonnet is free.
Mini Heki 400 x 400 mm
• This roof bonnet can be opened to three
different settings in the opposite direction to
trafc. Press the locking knob on the side and
use the adjusting lever to move the roof bon-
net to the desired position; then click it into
place. The bonnet has a maximum opening
angle of 50°.
Midi Heki 700 x 500 mm
• Pull out the crank to the user position. Turn the
crank clockwise to open the bonnet to the
desired position. When you have reached the
maximum opening angle of 60° you will feel
the resistance.
To close the roof bonnet
Mini Heki 400 x 400 mm
• Release adjusting lever from its position and
close roof bonnet. The bonnet is automatically
locked when it is completely closed.
Midi Heki 700 x 500 mm
• Turn the crank counter-clockwise until the
bonnet is closed and you feel the resistance.
When the bonnet is closed, you can fold the
crank back into the crank bag. To be locked
securely, the crank must be folded into the
crank bag. Check the lock by pressing your
hand against the glass.
Shade
The shade is innitely variable; simply pull the
handle to the desired position or until the lock
snaps into the handle of the insect screen.
Opening/closing the insect screen
Push the handle strip of the insect screen
against the handle strip of the pleating until the
lock snaps into the handle strips.
