QuickStart: FLIR i40, i50, i60
b40, b50, b60
© 2012 The Snell Group / 322 N. Main St. / Barre, VT 05641 / 800-636-9820 / www.thesnellgroup.com
FLIR i and b Series Page 2
Press the Right Select Button (Man/Auto) until the “M” appears in the lower right portion of the LCD.
(Fig.2)
Manually adjust Level and Span by selecting one of these three Icons by pressing the
Navigation Pad left or right.
Select the icon, then pressing up/down to adjust the upper and lower temperature values at the
same time.
Select the icon, then press up/down to adjust the lower temperature value.
Select the icon, then press up/down to adjust the upper temperature value.
7. PAUSE IMAGE: There is no pause or freeze function, You must first save an image then recall it (see below).
8. SAVE IMAGE: Pull and release the Trigger.
9. RECALL IMAGE: Press the Camera/Archive Button then do one of the following.
To display and find a single saved image press the Navigation Pad left/right.
To open an image press Open.
To display thumbnails of all saved images press the Navigation Pad up/down.
To select the thumbnail you wish to open use the navigation Pad up/down/left/right.
To open an image press Open.
10. PALETTE: Press the Left Select (Menu) Button to show the menu (Fig.2).
Using the Navigation Pad to move up and down, highlight Color palette then press the Left Select Button
again.
Now use the Nav. Pad up/down to highlight the desired palette.
Press select again to change the palette, close the menu and return to the image.
11. RANGE:
The b series have a single temperature Range: -4 to +248˚F(-20 to +120˚C)
The i series have a two temperature Ranges: -4 to +248˚F (-20 to +120˚C) 32 to 662˚F (0 to 350˚C)
To change the temperature range (i series only) press the Left Select (Menu) Button to show the menu.
Highlight the Settings menu option using the Navigation Pad up/down, then press select.
Highlight the Temperature Range menu option then press select.
Highlight the desired temperature then press select to execute change and return to a live image.
i40 & b40 Cameras
i50 & b50 Cameras
i60 & b60 Cameras
IFOV =2.42mRad (Theoretical with 180 x 180 Detector and standard 25˚x25˚ lens) Detect 1in. target @ 34.4ft.
IFOV =3.12 mRad (Theoretical with 140 x 140 Detector and standard 25˚x25˚ lens) Detect 1in. target @ 26.7ft.
IFOV =3.64mRad (Theoretical with 120 x 120 Detector and standard 25˚x25˚ lens) Detect 1in. target @ 22.8ft.
