15
*
[SR09370(ALL)05/95]
Automatic locking mode
*
[SR09380(ALL)07/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and will
remain locked when the combination
lap/shoulder safety belt is buckled, and does not
allow the occupant freedom of movement. This
mode provides the following:
*
[SR09390(ALL)07/95]
❑
A tight lap/shoulder belt on the occupant.
*
[SR09400(ALL)07/95]
❑
Child safety seat installation.
*
[SR09410(ALL)07/95]
RWARNING
Rear-facing infant seats should never be
placed in the front seats.
*
[SR09420(ALL)07/95]
This mode must be used when installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR09430(ALL)07/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR09440(ALL)07/95]
1. Buckle the lap/shoulder combination belt.
*
[SR09450(ALL)07/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted, and when allowed to retract, a
clicking sound will be heard. At this time,
the belt retractor is in the automatic locking
mode (child restraint mode).
*
[SR09460(ALL)07/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
automatic locking mode.
