Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
101 50A** Ignition Switch (B1 & B3)
102 30A** Power Door Locks
103 40A** Auxiliary Blower
104 30A** Electronic Shift On The Fly (Transfer
Case Motor)
105 50A** Junction Box Battery Feed
106 — (Gasoline
only)
30A**
(Diesel only)
Gasoline only-Not Used
Diesel only-Injector Driver Module
107 30A** Heated Seats
108 30A** Power Seats
109 40A** Front Blower Motor
110 30A** Trailer Tow Electronic Brake
111 — Not Used
112 20A** Fuel Pump
113 30A** (Gasoline
only)
20A**
(Diesel only)
PCM Power
114 — Not Used
115 30A** Trailer Tow Battery Charge
116 50A** Ignition Switch (B4 & B5)
117 — Not Used
118 40A** Rear Defroster
201 — Park Lamp
202 — Fuel Pump
203 — Not Used
204 — Quarter Flip Window Motor
205 — Rear Wiper
206 — Rear Washer
207 — Wiper Run/Park
