To remove the tonneau cover:
The tonneau cover needs to be
supported during removal. This is a
two person operation.
• Remove the cargo divider, refer
to To remove the cargo divider
on the previous page.
• Disconnect the hydraulic
cylinders from the pickup box
and secure them in the clips on
the tonneau cover. Close the front panel.
• Open and support the front panel.
• Stow the rear panel on top of the front panel, refer to To stow the
rear panel shown previously.
• Pull two release levers on the underside of the tonneau cover from the
pickup box and remove the tonneau cover.
For installation of the tonneau cover, reverse the removal procedure.
Driver Controls
62
