Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
R03 Hi-beam relay Fuse # 35, Hi-beam headlamps,
Hi-beam indicator
R04 Rear window
defrost relay
Fuse 8 (heated mirrors), Rear
window defroster, Heated outside
mirrors, Rear window defroster
indicator (climate control head)
R05 Trailer tow
battery charge
relay
Trailer tow 7–wire connector
(battery charge)
R06 Front blower
relay
Front blower motor
R201 Trailer tow park
lamp relay
Trailer tow 7–wire and 4–wire
connectors (park lamps)
R202 Foglamp relay Front foglamps
R203 PCM relay Fuse 32, Fuse 33, Fuse 34, Fuel
pump relay, Fuel pump, PCM
solenoids and sensors
R301 Trailer tow
back-up lamp
relay
Trailer tow 7–wire connector
(back-up lamps)
R302 Speed control
relay
Speed control servo
R303 Fuel pump relay Fuel pump shut-off switch, PCM
(fuel pump monitor), Fuel pump
R304 Battery saver
relay
Roof rail lamps, Vanity mirror
lamps, Map/Dome lamp, Glove box
lamp, Cargo area lamp, Outside
mirror puddle lamps, Instrument
cluster (interior lamps)
R305 Horn relay Dual note horn
* Mini Fuses ** Maxi Fuses
Note: Relays R301–R305 are not serviceable components; see your
dealer or a qualified technician for assistance.
2004 Expedition (exd)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
252
