Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
36 40A* Front A/C blower motor
37 30A** Front wiper, Front washer
38 5A** Heated Positive Crankcase Ventilation
(PCV) valve
39 — Not used
40 10A** TCM, EVMV, Canister vent, ESM,
Exhaust Gas Oxygen heaters, A/C
clutch
41 15A** PCM, Injectors, Ignition coils, Mass
Air Flow (MAF) sensor
42 — Not used
43 — Not used
44 — Not used
45 — Not used
46 — Not used
47 — Not used
48
1
⁄ 2 ISO relay Fog lamps
49 — Not used
50 — Not used
51
1
⁄ 2 ISO relay A/C clutch
52 — Not used
53
1
⁄ 2 ISO relay Fuel pump driver module, Fuel pump
54 — Not used
55 Full ISO relay PCM relay, PDB fuses 40 and 41
56 Full ISO relay Starter motor solenoid
57 Full ISO relay Front A/C blower motor
58 High current
relay
Wipers
59 — Not used
60 1A Diode PCM
61 1A Diode PCM
* Cartridge Fuses ** Mini Fuses
2005 Five Hundred (500)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
193
