4x2 w/manual transmission
Engine Rear
axle
ratio
Maximum
GCWR - lb.
(kg)
Maximum
trailer weight
- lb. (kg)
Maximum
frontal area of
trailer - ft
2
(m
2
)
Regular Cab w/7’ box
2.3L All 4800 (2177) 1520 (689) Equal to frontal
area of vehicle
3.0L* All 6000 (2722) 2580 (1170) 50 (4.64)
SuperCab
2.3L All 4800 (2177) 1420 (644) Equal to frontal
area of vehicle
3.0L* All 6000 (2722) 2460 (1116) 50 (4.64)
3.0L*
Edge
All 6000 (2722) 2360 (1070) 50 (4.64)
4.0L All 7000 (3175) 3400 (1542) 50 (4.64)
4.0L
Edge
All 7000 (3175) 3280 (1488) 50 (4.64)
For high altitude operation, reduce GCW by 2% per 1,000 ft. (300
meters) elevation.
*When towing on roads with steep grades or moderate but long
sustained grades (5 miles [8 km] or more), or when ambient
temperatures exceed 100°F (37°C), vehicle speed should not exceed
45 mph (72 km/h) in both cases.
For definition of terms used in this table see Vehicle Loading earlier
in this chapter.
To determine maximum trailer weight designed for your particular
vehicle, see Calculating the load your vehicle can carry/tow earlier
in this chapter.
Maximum trailer weight is shown. The combined weight of the completed
towing vehicle (including hitch, passengers and cargo) and the loaded
trailer must not exceed the Gross Combined Weight Rating (GCWR).
The Ranger is capable of pulling the maximum trailer weight(s) as
specified above. Certain states require electric trailer brakes for trailers
over a specified weight. The Ranger vehicle electrical system is not
equipped to accommodate electric trailer brakes.
2005 Ranger (ran)
Owners Guide (post-2002-fmt)
USA (fus)
Tires, Wheels and Loading
127
