Trip odometer: Registers the miles
(or kilometers) of individual
journeys. To reset, press and hold
the trip reset button for two or
more seconds; this returns the trip
odometer to zero. Press and release
the button to return to the
odometer display.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale (in the red zone) may
damage the engine. The pointer will
indicate engine RPMs when the
engine is running and point at the
EV symbol when the engine is off and the vehicle is running on pure
electrical power.
Fuel gauge: Indicates
approximately how much fuel is left
in the fuel tank (when the ignition
is in the ON position). The fuel
gauge may vary slightly when the
vehicle is in motion or on a grade.
Refer to Filling the tank in the
Maintenance and Specifications
chapter for more information.
2006 Escape Hybrid (hev)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
19
