Your vehicle’s load capacity is designated by weight, not by volume, so
you cannot necessarily use all available space when loading a vehicle.
Towing a trailer places an additional load on your vehicle’s engine,
transmission, axle, brakes, tires and suspension. Inspect these
components carefully after any towing operation.
4x2 w/manual transmission
Engine Rear
axle
ratio
Maximum
GCWR - lb
(kg)
Maximum
trailer weight
- lb (kg)
Maximum
frontal area of
trailer - ft
2
(m
2
)
Regular Cab w/6’ box
2.3L All 4800 (2177) 1580 (716) Equal to frontal
area of vehicle
2.3L Sport All 4800 (2177) 1520 (689) Equal to frontal
area of vehicle
Regular Cab w/7’ box
2.3L All 4800 (2177) 1540 (698) Equal to frontal
area of vehicle
SuperCab
2.3L All 4800 (2177) 1420 (644) Equal to frontal
area of vehicle
4.0L All 7000 (3175) 3400 (1542) 50 (4.64)
4.0L Sport All 7000 (3175) 3220 (1460) 50 (4.64)
For high altitude operation, reduce GCW by 2% per 1,000 ft.
(300 meters) elevation.
For definition of terms used in this table see Vehicle Loading earlier
in this chapter.
To determine maximum trailer weight designed for your particular
vehicle, see Vehicle Loading earlier in this chapter.
Maximum trailer weight is shown. The combined weight of the
completed towing vehicle (including hitch, passengers and cargo) and
the loaded trailer must not exceed the Gross Combined Weight Rating
(GCWR).
The Ranger is capable of pulling the maximum trailer weight(s) as
specified above. Certain states require electric trailer brakes for trailers
over a specified weight. The Ranger vehicle electrical system is not
equipped to accommodate electric trailer brakes.
2009 Ranger (ran)
Owners Guide, 2nd Printing
USA (fus)
Tires, Wheels and Loading
144
