4. Open the hood. Protect yourself from engine heat.
5. Locate and carefully remove the engine oil level dipstick.
• 2.3L I4 engine
• 4.0L SOHC V6 engine
6. Wipe the dipstick clean. Insert the dipstick fully, then remove it again.
• If the oil level is between the two holes or between the MIN and
MAX marks (depending on application), the oil level is acceptable,
DO NOT ADD OIL.
• If the oil level is below the lower hole or the MIN mark, add enough
oil to raise the level between the two holes or between the MIN-MAX
range.
MAXMIN
2009 Ranger (ran)
Owners Guide, 2nd Printing
USA (fus)
Maintenance and Specifications
230
