ONE | HEADLAMPS AND FOG LAMPS
Turn the control oneposition to the right to turn on the parking lamps, instrumentpanel
lamps, license plate lamps and tail lamps. Turn the control to the second position on the
right to turn on the headlamps. Turn the control one position to the left to activate
the autolamp feature (if equipped),which automatically turns the exterior lamps on and off,
based on available daylight. Pull the control towards you to activate the fog lamps, if
equipped.(The fog lampswill not operatewhen the controlis turned off ( ) or when thehigh beams areon).
TWO | PANEL DIMMER
Use this control to adjust the brightness of the instrument panelan dall applicable switches
in the vehicle during headlamp and parking lamp operation. Move the control to the full
upright position, past the detent, to turn on the interior lamps.
THREE | ADJUSTABLEPEDALS (IF EQUIPPED)
Press the top of the control to move the pedals further away from you or press the bottom
of the control to move the pedals closer to you. The pedals should only be adjusted when
the vehicle is stopped and in Park (P).
FOUR | HOOD RELEASE
To open the hood, pull the hood release handle under the bottom of theinstrument panel,
near the steering column. Go to the front of the vehicle and release the auxiliary latch
located under the front center of the hood. Use the prop rod to support the raised hood.
FIVE | SPEEDCONTROL
To set the speed control, press and release ON. Accelerate to the desired speed. Press and
release the SET + control. Take your foot off the accelerator pedal. The speed control
indicator light will illuminate in the cluster. To set a higher speed: press and hold SET+
until the desired speed is reached, or briefly press SET+ to increase the speed by small
amounts. To set a lower speed: press and hold SET- until the desired speed is reached, or
briefly press SET-to decrease the speed by small amounts. Press RSM to return tothe previously set speed.
To turn speed control off, depress the brake pedal or press OFF or CNCL (Cancel).
SIX | TILT STEERING COLUMN
To adjust the steering wheel, push the adjustment lever down to unlock the steering
column. While the lever is down, tilt the steering column to your desired position. While
holding the steering column in place, pull the lever up to its original position to lock the
steering column. Do not adjust while driving.
SEVEN | STEERINGWHEEL AUDIO CONTROLS
Audio Steering Wheel Controls: The appearance and functionality of your vehic le’s
steering wheel controls may vary accordingto your option package. Refer to your Owner’s
Guide for a complete description of all possible options. Press – VOL + t o
decrease/increase the volume. Press – SEEK + to access theprevious/next strongstation
or CD track. Press MEDIA repeatedly to scroll through all possible media sources (AM,
FM1,FM2, CD . . .etc). Press MUTE to mute the playing media. Press again to return to the playing media.
SYNC Steering Wheel Controls (if equipped): Press to activate the Voice recognition
system. Press to answer a call if equipped with SYNC. Press and hold to end a call.
Refer to your SYNC supplement for more information. Press OK to confirm menu
selections. Refer to your SYNC supplement (if equipped) for more information.
EIGHT | MULTI-FUNCTION LEVER
Rotate the end of the control up to increase the speed of the wipers and rotate down to
decrease the speed of the wipers. Briefly press the end of the stalk for a single swipe of
the wipers without washer fluid. A quick push and hold results int hreeswipes with washer
fluid while a longer push and hold activates the wash pattern for up to five seconds. For
better visibility, your vehicle will automatically turn on your headlights if your windshield
wipers and autolamps (if equipped) are on. To operate your rear window wiper, turn
the rear wiper control to 1 (intermittent speed), 2 (normal speed), or off. For a rear wash cycle, turn the
rear wiper control to the position. Your rear wiper blades are automatically heated to help reduce any
ice build up on your rear windshield.
TEN TWELVE THIRTEEN
NINE | THROTTLE CONTROL/
TRANSMISSION LAMP
The throttle control/transmission light il luminates when
a powertrain or an AWD faulthas been detected. Contact your
authorized dealeras soon as possible.
TEN | MESSAGE CENTER
The message center displays important vehicle information by
constantly monitoring vehicle systems. You may select display
features on the message center for a display of status. The
systemwill also notifyyou of potentialvehicle problems with a
display of system warnings. For more information, please
consultyour Owner’s Guide.
ELEVEN | LOW TIREPRESSUREWARNING
Your vehicle is equipped with a Tire Pressure Monitoring
System(TPMS). Thisindicatorlight illuminateswhen your
tire pressure islow. Whenthe ignitionis turned on,the light will
illuminate fora few seconds toensure thatthe bulb is working.
If the light remains on, or begins to flash, check the tire
pressure. Ifthe issuepersists,have thesystem inspected byan
authorized dealer. For moreinformationon this system, refer to
Tire Pressure Monitoring System in yourOwner’s Guide.
TWELVE | SERVICE ENGINE SOON
The service engine soon light illuminates when the
ignition is first turned on to check the bulb. If the lamp
turns solid or blinks, the On Board Diagnostics System
has detected a malfunction. Drive in a moderate fashion
(avoid heavy acceleration or deceleration) and have your
vehicle serviced immediately.
THIRTEEN | ABS WARNING LIGHT
The ABS light illuminates briefly when the ignition is
turned on. If the ABS light remains on or continues to
flash, a malfunction has been detected. Have the system
serviced immediately by your authorized dealer. Normal
braking (less ABS) is still functional unless the brake
warning light is also illuminated.
ELEVENNINE
TAURUS X
2009
QUICK REFERENCE GUIDE
INSTRUMENT PANEL AND
INTERIOR
FEATURES
LOCATION OF SPARETIRE
If you get a flat tire while driving, do not apply the brake
heavily. Instead, gradually decrease your speed. Hold the
steering wheel firmly and slowly move to a safe place on
the side of the road. Your vehicle is equipped with a
temporary spare tire. The spare tire and jack are located
under the carpeted floor panelin the rear of the vehicle. If
the 3rd row seat is stowed in the floor, you will need to
unstow it to gain access to the spare tire and jack. The
temporary spare is designed for emergency use only and
should be replaced as soon as possible. For complete
details on how to change your tire, refer to the Roadside
Emergencies chapter in your Owner’s Guide.
FUSES
If your electrical components are not working properly, a
fuse may haveblown. Please consult yourOwner's Guide.
FUELTYPE ANDTANK CAPACITY
Depending on whether you have a Front Wheel Drive
(FWD) or All WheelDrive (AWD) vehicle and if yourvehicle
has a special emissions package, your fuel tank capacity
will either be 20 gallons (75.7L) or 20.5 gallons (77.6L).
Your vehicle is designed to use “Regular” unleaded
gasoline with an octane rating of 87. Do not use gasoline
labeled as “Regular” in high altitude areas that are sold
with octane ratings less than 87. Your vehicle was not
designed to run on E85 fuels that are blended with a
maximum of 85% ethanol.
ALLWHEELDRIVE (AWD) (IFEQUIPPED)
Your vehicle may be equipped with All Wheel Drive (AWD).
The AWDsystem is always active and uses all fourwheels to
power the vehicle. This increases traction, enabling you to
driveover terrainand road conditions that a conventionaltwo-
wheel drive vehicle cannot. Refer to your Owner’s Guide for
more information.Note: If your vehicle is equipped withAWD,
a spare tire of a different size (other than the tire provided)
should neverbe used. Using a different size could cause the
AWD system to stop functioning and default to front wheel
drive. Your vehicle is not intended for off-roaduse.
TIRE PRESSURE
Your tire pressure is properly set at the dealership
according to the recommended specifications found on
the Safety Compliance Certification Label or Tire Label
located on the B-Pillar or the edge of the driver’s door.
Check your tire pressure at least once a month and
before long trips (including spare). As an added safety
feature, your vehicle has b een equipped with a Tire
Pressure Monitoring System (TPMS) that illuminates
a low tire pressure warning light when one or more
of your tires is significantly under-inflated. Improperly
inflated tires can affect vehicle handling and can fail
suddenly, possibly resulting in loss of vehicle control.
Refer to the Tires, Wheels and Loading chapter in your
Owner’s Guide for more details and safety information.
ROADSIDE ASSISTANCE
Your new Ford Taurus X comes with the assurance and
support of 24-hour e mergency roadside assistance.
Roadside assistance includes such services as: lockout
assistance,limited fuel delivery, batteryjump starts,changing
a flat tire, towing, and winch out. To receive roadside
assistance in the United States, call 1 (800) 241-3673. In
Canada, call 1 (800) 665-2006. For more information on
coverage period and details of service, refer to your
Roadside Assistance information card.
S.O.S.POST CRASH ALERT SYSTEM
Your vehicleis equipped with the S.O.S. Post Crash Alert
system. This systemprovides audible and visualalarms in
the event of a crash which causes the deployment of
airbags or the activation of the safety belt pretensioners.
The turn signals will flash and the horn will sound. To
deactivatethe system, pressthe hazard flashercontrol
(located on the instrument panel by the radio), or you can
pressthe button onyour remotetransmitter.
HAZARD FLASHER CONTROL
Press to activate the front and rear direction signals
when your vehicle is disabled and is creating a safety
hazard for other motorists. Press again to turn off.
2005 TAURUS X
ESSENTIAL
INFORMATION
“YOUR
ADVENTURES
ARE ABOUT TO BEGIN.”
ONE
TWO
THREE
FOUR FIVE SIX
SEVEN EIGHT
Use extreme caution when using any device or
feature that may take your attention off the
road. Your primary responsibility is the safe
operation of the vehicle. Onlyuse non-essential
features and devices when it is safe to do so.
Your new Ford Taurus X speaks volumes without saying a word.
Not only does the Taurus X surround you with sleek, trim good
looks and unexpected luxury, but it surrounds you with safety too.
Winning the Highway Traffic Safety Administration’s highest 5 star
rating for front, side and rear crash tests, your new Ford Taurus X
is rated as the safest seven passenger crossover in America. Now
that’s something. It’s listing as a ‘top safety pick’ is no surprise
with features like the Safety Canopy™ system, the Personal
Safety system™, optional All Wheel Drive, standard electronic
stability control, the S.O.S. Post Crash Alert System as well as the
SPACE™ architecture (Side Protection and Cabin Enhancement);
which utilizes advanced crash force management techniques to
help channel impact forces around and away from the passenger
cabin. All of this adds up to complete 5-star protection in the
spacious and comfortable Taurus X crossover.
