The engine coolant temperature gauge can be enabled or disabled. See
Base message center in this chapter for information on changing the
display settings.
• AWD gauge (if equipped and
enabled): Indicates AWD status.
See All-Wheel Drive (Awd) system
in the Driving chapter for
information.
3. Speedometer: Indicates the current vehicle speed.
4. Fuel gauge: Indicates approximately how much fuel is left in the fuel
tank (when the ignition is in the on position). The fuel gauge may vary
slightly when the vehicle is in motion or on a grade. The fuel icon and
arrow indicates which side of the vehicle the fuel filler door is located.
Optional cluster shown in standard measure–metric similar
1. Multifunction display: This displays the fuel gauge, tachometer,
engine coolant temperature, odometer/trip meter and other vehicle
features. This is also used to configure different vehicle personalization
options and display the status of various vehicle functions. See Optional
message center in this chapter for more information.
2. Speedometer: Indicates the current vehicle speed.
km/h
80
60
40
20
0
20
0
40
60
80
100
120
140
160
180
200
220
100
120
140
MPH
1 3
2
Instrument Cluster
19
2011 Edge (edg)
Owners Guide, 2nd Printing
USA (fus)
