3. Pull the bulb straight out of the
socket and push in the new bulb.
To complete installation, follow the
removal procedure in reverse order.
Replacing fog lamp bulbs (if equipped)
1. Make sure the fog lamp switch is
in the off position.
2. From underneath the vehicle,
carefully disconnect the electrical
connector from the bulb.
3. Remove the bulb from the lamp
assembly by pulling out on the bulb
while squeezing on the upper and
lower snap clips at the same time.
Install the new bulb in reverse
order.
Lights
68
2011 Escape Hybrid (ehv)
Owners Guide, 1st Printing
USA (fus)
