Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
11 10A Security module
12 7.5A Power mirrors
13 5A Not used (spare)
14 10A Center information display,
Electronic finish panel, GPS
15 10A Climate control
16 15A Not used (spare)
17 20A Power door locks, Trunk release
18 20A Not used (spare)
19 25A Navigation amp
20 15A Diagnostic connector
21 15A Fog lamps
22 15A Park lamps, License lamps
23 15A High beam headlamps
24 20A Horn
25 10A Demand lighting (battery saver)
26 10A Cluster (battery)
27 20A Ignition switch feed
28 5A Audio mute (start)
29 5A Camera (run/start)
30 5A Temperature sensor motor
31 10A Restraints control module (RCM)
32 10A Not used (spare)
33 10A Not used (spare)
34 5A Electronic stability control
35 10A Auxiliary body module (ABM)
run/start
36 5A Passive anti-theft system (PATS)
37 10A Not used (spare)
38 20A Not used (spare)
39 20A Radio/Navigation
Roadside Emergencies
227
2011 05+ Mustang (197)
Owners Guide, 2nd Printing
USA (fus)
