Fujitsu ABYG18KRTA User Manual

¢ Indoor unit: 22,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *
1
15 — — — 0.978 0.969 0.953
10 — — 0.986 0.986 0.977 0.961
5 — 0.992 0.994 0.994 0.984 0.968
2.5 0.996 0.996 0.998 0.998 0.988 0.972
0 1.000 1.000 1.002 1.002 0.992 0.976
Indoor unit is lower
than outdoor unit *
2
-2.5 1.000 1.000 1.002 1.002 0.992 0.976
-5 — 1.000 1.002 1.002 0.992 0.976
-10 — — 1.002 1.002 0.992 0.976
-15 — — — 1.002 0.992 0.976
Heating
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *
1
15 — — — 0.964 0.939 0.913
10 — — 0.988 0.964 0.939 0.913
5 — 1.000 0.988 0.964 0.939 0.913
2.5 1.000 1.000 0.988 0.964 0.939 0.913
0 1.000 1.000 0.988 0.964 0.939 0.913
Indoor unit is lower
than outdoor unit *
2
-2.5 0.998 0.997 0.986 0.962 0.937 0.911
-5 — 0.995 0.983 0.959 0.934 0.909
-10 — — 0.978 0.954 0.929 0.904
-15 — — — 0.949 0.925 0.899
¢ Indoor unit: 24,000 Btu/h
Cooling
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *
1
15 — — — 0.978 0.969 0.953
10 — — 0.986 0.986 0.977 0.961
5 — 0.992 0.994 0.994 0.984 0.968
2.5 0.996 0.996 0.998 0.998 0.988 0.972
0 1.000 1.000 1.002 1.002 0.992 0.976
Indoor unit is lower
than outdoor unit *
2
-2.5 1.000 1.000 1.002 1.002 0.992 0.976
-5 — 1.000 1.002 1.002 0.992 0.976
-10 — — 1.002 1.002 0.992 0.976
-15 — — — 1.002 0.992 0.976
Heating
Pipe length
m 2.5 5 10 15 20 25
Height difference H (m)
Indoor unit is higher
than outdoor unit *
1
15 — — — 0.964 0.939 0.913
10 — — 0.988 0.964 0.939 0.913
5 — 1.000 0.988 0.964 0.939 0.913
2.5 1.000 1.000 0.988 0.964 0.939 0.913
0 1.000 1.000 0.988 0.964 0.939 0.913
Indoor unit is lower
than outdoor unit *
2
-2.5 0.998 0.997 0.986 0.962 0.937 0.911
-5 — 0.995 0.983 0.959 0.934 0.909
-10 — — 0.978 0.954 0.929 0.904
-15 — — — 0.949 0.925 0.899
- 535 -
7-1. Model: AOYG36KBTA5
7. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOYG36KBTA5 OUTDOOR UNIT AOYG36KBTA5

Fujitsu ABYG18KRTA Specifications

General

Brand	Fujitsu
Model	ABYG18KRTA
Category	Air Conditioner
Language	English
