RX2530 M1
Operating Manual 59
6 Starting up and operation
V CAUTION!
Please note the safety instructions in chapter "Important information" on
page 33.
6.1 Control elements and indicators
6.1.1 Front of the server
Figure 6: Buttons and indicators on the front panel module
Figure 7: Buttons and indicators on the front panel on QRL
1 Reset button 5 Global Error indicator
2 NMI button 6 HDD / SSD activity indicator
3 ID button / ID indicator 7 On/Off button / power-on indicator
4 CSS indicator 8 AC connected indicator
