Furuno 1945 Quick Guide

Target A
1
Target A
2
Target A
3
Data off
Rain
Control
ON
Own ship’s position
The vessel behind
an island
AUTO
Auto Tuning
(Sensitivity)
Enhanced
Sunlight Viewable
Enhanced
Sunlight Viewable
Bonded LCD
Bonded
LCD
AIS
AIS
Target Tracking
Target
Tracking
s
Easy-to-install 10.4" portrait color LCD (350 cd) display
s
Bonded LCD provides clear view in all weather conditions
s
Stable AIS/Target Tracking with zoom display function
s
Full Screen Mode lets operators observe a wider range
around the vessel
s
Enhanced auto tuning/gain/anti-clutter controls
s
Echoes in yellow, green, orange or multiple colors
WithFullScreenMode,theentirescreenisfilled
withanechoimage.Full-screenechopresentation
capabilityallowstheoperatortoobserveawider
overviewofthesurroundingarea.
Full Screen Mode
Short Range Target Discrimination
Withapushofthe“OFFCENTER”button,ownshippositionisshiftedtoapre-registeredpointonthescreen.
Thisallowstheoperatortofocusonaspecificareaaheadoforaroundthevesselwithoutlosingtrackoftheposition.
Clearancebetweenmarkings
ofthebearingscaleis
changedaccordingtothe
proximitybetweenownship
andthebearingcircle,as
shownintheimagesonthe
left-handside.
Ithelpstograspthebearing
tothetargetechowithout
usingEBL.
Full Screen Mode with no NAV data
Off center mode
Normal mode
Bringing a New Level of Quality, Operability,
and Reliability into Marine Radar.
Furuno's new Radar series, 1835/1935/1945, is a high contrast 10.4" color LCD radar designed for a wide range of
vessels including pleasure craft, fishing boats and work boats.
These new Radars offer crystal clear target presentation with automatic Gain, Sea and Rain controls to deliver a
noise-free Radar presentation. It features superb detection of even small targets both at short and long ranges. It also
incorporates new display modes (ex. True View Mode, Full Screen Mode) which will assist with safe navigation. The
1835/1935/1945 series allows you to see far away objects before they are visible and allows you to see in the dark, fog
or during periods of obstructed visibility in any weather condition.
These Radars can be inter-connected with other navigation equipment, chart plotters and sounders, through Furuno's
programmable NMEA 0183 interface, which affords operators the ability to expand their boat's system as needed.
Thin piers standing in front of a beach.
ThereisalsoanoptiontoclearthenavigationdataontheRadardisplay.
IndividualnavigationdatacanbeeasilytoggledONorOFFinthededicatedmenu.
Withitsadvancedsignalprocessingtechnology,
the1835/1935/1945seriesdemonstrates
substantialincreasesintargetdetection,particularly
incloserange.Asshowninthepicturesonthe
right,theRadarclearlydisplaysthinpiersfroma
veryshortdistance.
Off Center Mode
Full screen mode
Addingtotheenhancedautocluttercontrols,dedicatedrotaryknobsareprovidedforthesuppressionofunwantedechoesfromsea
clutter,rainandotherformsofprecipitation.Anti-cluttersettingscanbeadjustedmanuallytoremoveseaandrainclutterfromtheRadar
screentogainaclearerviewofRadartargets.
Anti-Clutter Controls
Rain disturbs target recognition on the Radar screen.
Featuringdedicatedrotaryknobstoadjust
GAIN/STC/FTCforstraightforwardoperation.
Upto100AISand10TTtargetscanbetrackedandoverlaidontheRadarscreentoassisttheoperatorintrackingvessel
movements.SinceAISworksbyaVHFtransceiversystem,avarietyofnavigationalinformationsuchasvesselname,speed,ROT,
draft,andthedestinationoftheselectedtargetscanbeincludedinrealtime.UnlikeTTtargets,AIStargetsarevisibleeveniftheyare
locatedbehindlargeshipsorislands.
Optional supply required
AIS targets can show that a vessel is coming from behind
an island, where a Radar beam does not reach.
TT Target
AIS Target
Target Zoom
AtargetcanbeshowninazoomdisplaywhileitsdetailedmovementsaretrackedbyAISorTT.
Theconventionalzoomfunctionisalsoavailablebywhichtheoperatorsetsthezoomfunctiononthetargetmanually.
Target acquired and tracked. Target shifts its position.
Zoom box tracks the target object
according to its movement.
AIS / Target Tracking
(
TT
)
Display
10.4 Multi-Color LCD RADAR
10.4 Multi-Color LCD RADAR
SPECIFICATIONS OF MODEL 1835/1935/1945
ANTENNA RADIATOR
Type
 MODEL1835 Printedarray
 MODEL1935/1945 Slottedwaveguidearray
Length and Rotation Speed
 MODEL1835 Radome60cm(RSB-0071)24RPM
 MODEL1935 Open100cm(XN10A)24or48RPM
 MODEL1945 Open120cm(XN12A)24or48RPM
Wind Load (for MODEL 1935/1945)
 24RPM 100knrelativewind
 48RPM 70knrelativewind
Beamwidth
 ANT9210: Hor.4.0°,Vert.20°
 XN10A: Hor.2.4°,Vert.22°
 XN12A: Hor.1.9°,Vert.22°
RF TRANSCEIVER
Frequency
9410±30MHz(X-band)
Output Power

MODEL1835/1935 4kW
 MODEL1945 6kW
DISPLAY
Screen Size
10.4"colorLCD
Pixel Number
640(H)x480(V),VGA
Effective Diameter
158mm
Echo Colors
32levels
Display Modes
Head-up,Course-up*,North-up*,
 Trueview*,Truemotion**
  *Headingdatarequired
  **Headingandpositiondatarequired
Range Units
nm,sm,km
Range Scales and Range Ring Intervals (nm)
 Range: 1/16,1/8,1/4,1/2,3/4,1,1.5,1.6,2,3,
 3.2,4,6,8,12,16,24,32,36,48*,64**
 Rings: 1/32,1/16,1/8,1/4,1/2,0.8,1,2,3,4,
 6,8,12*,16**
  *ForMODEL1935/1945
  **ForMODEL1945
Minimum Range
25m
Range Discrimination
25m
Echo Trails
 Type Trueorrelativetrails
 TrailLength: 15,30sec.,1,3,6,15,30min.,
 orcontinuousTrail
 TrailWidth: Narrow,Normal
Target Tracking (Required optional board ARP-11)
 Acquisition:Auto,Manual
 Numberoftargets:10targetsmax
AIS Functions (Data input from AIS is required)
 Symbols:Sleeping,Activated,Dangerous,Selected,Losttargets
 Numberoftargets:100targetsmax.
INTERFACE
Input
AD-10orIEC61162NMEA0183Ver.1.5/2.0/3.0
Output
IEC61162NMEA0183Ver.1.5/2.0/3.0
ENVIRONMENT
Temperature
 AntennaUnit: -25°Cto+55°C(-13°Fto+131°F)
 DisplayUnit: -15°Cto+55°C(5°Fto+131°F)
Waterproofing
 AntennaUnit: IEC60529IP26
 DisplayUnit: IEC60529IP55
POWER SUPPLY
 MODEL1835 12-24VDC:4.1-2.0A
 MODEL1935 12-24VDC:6.8-3.3Afor24rpm
  8.2-3.8Afor48rpm
 MODEL1945 12-24VDC:7.3-3.5Afor24rpm
  8.8-4.1Afor48rpm
EQUIPMENT LIST
Standard
1.DisplayUnit  1unit
2.AntennaUnit(Specifywhenordering) 1unit
3.AntennaCable
 MODEL1835  10,15,20or30m1pc
 MODEL1935/1945  10,15,20or30m1pc
4.PowerCable5m1pc.
5.Installationmaterialsandspareparts 1set
Option
1.AutoPlotterARP-11
2.Rectifier
 MODEL1835  PR-62
 MODEL1935/1945  RU-3423
3.
ExternalAlarmBuzzer  OP03-21
4.InterfaceCable
 MJ-B24LPF0010  10,20,or30m
 MJ-A7SPF0007-050C 5m
 MJ-A6SPF0007-100C 10m
 MJ-A10SPFW0001+R 0.2m
5.AntennaBracket(forMODEL1835) OP03-92
12033SK Printed in Japan
Catalogue No. R-196b
www.furuno.com
COLOR LCD SOUNDER 10.4 Multi-Color LCD RADAR
All brand and product names are registered trademarks, trademarks
or service marks of their respective holders.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
1835/1935/1945
Model
1835/1935/1945
Model
1835/1935/1945
ModelModel
AUTO
Auto Tuning
(Sensitivity)
Enhanced
Sunlight Viewable
Enhanced
Sunlight Viewable
Bonded LCD
Bonded
LCD
AIS
AIS
Target Tracking
Target
Tracking
MODEL 1835 and FCV-295 Helm Solution
The cosmetic design of the 1835/1935/1945 Radar series matches with that of the FCV-295 digital echo sounder with
10.4" bonded LCD. Installed side-by-side, they will enhance the look of your helm.
285 11.2"
310 12.2"
323 12.7"
308 12.1"
169
6.7"
129 5.1"
17
0.7"
22 0.9"
35°
25
1.0"
62 2.4"
BOW
Cable entry
278 10.9"
602 23.7"
348 13.7"
266 10.5"
Cable entry
(160 6.3")
(160 6.3")
Fixing holes
4-M10
640
25.2"
BOW
445 17.5"
357 14.1"
542 21.3"
250 9.8"
213 8.4 "
438 17.2"
340 13.4"
250 9.8"
XN10A :1036 40.8"
XN12A :1255 49.4"
4- 15
Fixing holes
200 7.9"
200 7.9"
25
100/110/115/
220/230VAC
12-24 VDC
MJ-B24LPF0002
10/15/20/30 m
MJ-B24LPF0005
10/15/20/30 m
MJ-A10SPFW
0001+R
MJ-A7SPF
0007-050C
MJ-B24
LPF-0010
MJ-A7SPF0007-050C
MJ-A7SPF0007-050C
MJ-A6SPF0007-100C
Display Unit
RDP-152
5.4kg11.9lb
Antenna Unit
RSB-0071
8kg17.6lb
Antenna Unit
XN10A:22kg48.5lb
XN12A:25kg55.1lb
Display Unit
ARP-11
GPS Navigator, AIS
Sounding Equipment
Satellite Compass
SC-30*/50/110
Heading Sensor
PG-500
*For further info, contact our depot
Option or local supply
Gyro Converter AD-100
Rectifier
GPS Navigator, AIS
Sounding Equipment
Gyrocompass
External Alarm Buzzer
for MODEL 1835
Remote Display*
INTERCONNECTION DIAGRAM
Antenna Unit
for MODEL 1935/1945
