2. OPERATIONAL OVERVIEW
2-7
2.3 Standby Display
After the equipment is turned on and the diagnostic test is completed, the standby dis-
play appears, showing the results of the test. The system status monitor provides var-
ious operating information. For further information, see section 8.4.
After the diagnostic test is completed, the equipment automatically starts synchroniz-
ing itself with a satellite. When the indication "Retuning" is replaced with
"SYNC(NCS)", the synchronization process is completed. Then, you are ready to re-
ceive EGC messages. See section 3.4.
File Edit Transmit EGC Reports Logs Options Setup StopAlarm
Date
Time
Position
Waypoint
Course 345.5 DEG
Speed 10.2 kn
Current NCS
Current Channel
Current TDM
MES Status
GPS Status
DCE Memory
Jan-12-12
01:32 (UTC)
LAT 34:30.00N
LON 135:00.00E
LAT
LON
344 (IOR) LOGOUT
NCS CC
NCS CC
Idle
****
32818 Bytes free
IMN:
BBER
C/N
Send Level
Rx AGC Level
REF Offset Freq
Synthe Local
TCXO Control 131
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
443156710
000
OK ( 0 dB)
OK ( 0)
OK (254)
OK ( 0 Hz)
OK
OK(7.vX)
Current State: IDLE
DCE F19 Ver. xx
Retuning
NCS: IOR LOGOUT LAT: 34:30.00N
REC. MESSAGE EXISTS LON: 135:00.00E
Jan-12-12 01:32 (UTC)
68.2 DEG
232 DEG
1.9 kn
xx: Program Version No. of COMMCPU Board
To Next Page
