2. WIRING
2-26
Connector J3
Connector J4
Connector J5
Connector J6
Pin
#
Signal name
In/
Out
Remarks
ACK1
contact
ACK1 voltage
ACK2
contact
ACK2 voltage
1 DC12V_OUT Out ACK1 In Pin #1-#2:
short
No connection
-
2 DIGI_IN1 In MPYC-12
3 DIGI_RTN1 Out MPYC-12
4 GND (DC12V) In No connection
5 DC12V_OUT Out ACK2 In
-
Pin #5-#6:
short
No connection
6 DIGI_IN2 In MPYC-12
7 DIGI_RTN2 Out MPYC-12
8 GND (DC12V) In NO connection
Pin
#
Signal name
In/
Out
Remarks
ACK3
contact
ACK3
voltage
ACK4
contact
ACK4 voltage
1 DC12V_OUT Out ACK3 In Pin #1-#2:
short
No connection
-
2 DIGI_IN3 In MPYC-12
3 DIGI_RTN3 Out MPYC-12
4 GND (DC12V) In No connection
5 DC12V_OUT Out ACK4 In
-
Pin #5-#6:
short
No connection
6 DIGI_IN4 In MPYC-12
7 DIGI_RTN4 Out MPYC-12
8 GND (DC12V) In No connection
Pin
#
Signal name
In/
Out
Remarks
ACK5
contact
ACK5 voltage
ACK6
contact
ACK6
voltage
1 DC12V_OUT Out ACK5 In Pin #1-#2:
short
No connection
-
2 DIGI_IN5 In MPYC-12
3 DIGI_RTN5 Out MPYC-12
4 GND (DC12V) In No connection
5 DC12V_OUT Out ACK6 In
-
Pin #5-#6:
short
No connection
6 DIGI_IN6 In MPYC-12
7 DIGI_RTN6 Out MPYC-12
8 GND (DC12V) In No connection
Pin
#
Signal name
In/
Out
Remarks
ACK7
contact
ACK7
voltage
ACK8
contact
ACK8 voltage
1 DC12V_OUT Out ACK7 In Pin #1-#2:
short
No connection
-
2 DIGI_IN7 In MPYC-12
3 DIGI_RTN7 Out MPYC-12
4 GND (DC12V) In No connection
5 DC12V_OUT Out ACK8 In
-
Pin #5-#6:
short
No connection
6 DIGI_IN8 In MPYC-12
7 DIGI_RTN8 Out MPYC-12
8 GND (DC12V) In No connection
