Furuno GP-150 Installation Manual

INSTALLATION MANUAL
GPS NAVIGATOR
GP-150
1. SYSTEM CONFIGURATIONS .......................................................................... 1
2. EQUIPMENT LIST............................................................................................ 2
3. DISPLAY UNIT..................................................................................................4
4. ANTENNA UNIT................................................................................................ 6
5. WIRING ...........................................................................................................10
6. INITIAL SETTINGS.........................................................................................12
7. OPTIONAL DGPS........................................................................................... 23
PACKING LISTS & INSTALLATION MATERIALS........................................... A-1
OUTLINE DRAWINGS...................................................................................... D-1
INTERCONNECTION DIAGRAM ......................................................................S-1

Furuno GP-150 Specifications

General

Display Type	LCD
Display Size	4.5 inches
Resolution	320 x 240 pixels
Channels	12
Operating Temperature	-15°C to +55°C
Waterproof Rating	IPX5
Data Output	NMEA 0183
Type	GPS Receiver
Accuracy	10 meters
Languages	English
