FUTABA 7PX User Manual

Home screen
Menu screen
Menu-2
Menu-1
Linkage menu
Channel Limiter
For S-FHSS (analog) system, 5 to
7 channels are displayed on the
2nd page.
Tap to change page.
74
Function
Channel Limiter
Channel limiter
The channel limiter function limits maximum servo movement. By superimposing mixing,
the linkage can be protected by setting the limiter in case servo motion becomes unexpect-
edly large.
(Preparation)
- Tap the travel button of the channel you want to set. Value in-
put buttons appear on the screen.
1
Use the [+] or [-] buttons to adjust the servo
angle.
Channel limiter adjustment
2
When fi nished, return to the Linkage menu screen by pressing the HOME button.
Adjust button
Adjust with the [+] and [-] but-
tons.
- Return to the initial value by
tapping the [reset] buttons.
Limiter rate
0~145
Initial value: 145
1M23N32602_7PX_E.indb 74 2017/08/02 14:17:22

FUTABA 7PX Specifications

General

Channels	7
Frequency	2.4GHz
Telemetry	Yes
Data Logging	Yes
Model Memory	40 models
Compatibility	T-FHSS, S-FHSS
System	T-FHSS
Display	4.3 inch color TFT LCD touch screen
