8 GHP 10 Marine Autopilot System Installation Instructions
Dual-helm Layout Guidelines
NMEA 2000 network
CCU
ECU
Pump (1.2 L pictured)
GHC 10
12 Vdc*
GHC 10
NOTE: This diagram is for planning purposes only. Specic wiring diagrams are included in the detailed installation instructions for
each component. Hydraulic connections are not shown in this diagram.
* Newer ECU units are compatible with 24 Vdc systems. See page 25 for more information.* Newer ECU units are compatible with 24 Vdc systems. See page 25 for more information.

Garmin GHP 10 Specifications

General

Navigation protocols	NMEA 2000
Traffic Message Channel (TMC)	-
Operating temperature (T-T)	-15 - 70 °C
Form factor	Handheld/Fixed
Product color	Gray
Built-in camera	No
Display diagonal	- \
Display size (HxV) (imperial)	320 x 240 \
Auto	Yes

Weight and Dimensions

Depth	48 mm
Width	109 mm
Height	112 mm
Weight	- g
