CHAPTER 1: COMMUNICATIONS GUIDE ETHERNET INTERFACE
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–41
DNP port allocation
The DNP Eth Channel 1 Port and DNP Eth Channel 2 Port settings select the
communications port assigned to the DNP protocol for each Ethernet channel. When this
setting is set to "Network-TCP" the DNP protocol can be used over TCP/IP channels 1 or 2.
When this value is set to "Network-UDP" the DNP protocol can be used over UDP/IP on one
channel only.
Default Counter Object/Variation: Counters Roll Over at:
□ No Counters Reported □ No Counters Reported
□ Configurable (attach explanation) □ Configurable (attach explanation)
⊠ Default Object: 20 ⊠ 16 Bits
Default Variation: 1
⊠ Point-by-point list attached □ Other Value: _____
⊠ Point-by-point list attached
Sends Multi-Fragment Responses:
⊠ Yes
□ No
DNP 3.0 Device Profile
Channel 1 Port Channel 2 Port DNP Availability
None None DNP not available over Ethernet port
None NETWORK-TCP One Master over TCP
None NETWORK-UDP "Various" Masters over UDP
NETWORK-TCP None One Master over TCP
NETWORK-TCP NETWORK-TCP Two Masters over TCP
NETWORK-TCP NETWORK-UDP One Master over TCP and "various" Masters over UDP
NETWORK-UDP None "Various" Masters over UDP
NETWORK-UDP NETWORK-TCP "Various" Masters over UDP and one Master over TCP
NETWORK-UDP NETWORK-UDP "Various" Masters over UDP
