3-34 SR3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
SUMMARY OF ETHERNET CLIENT CONNECTIONS CHAPTER 3: ETHERNET INTERFACE
Summary of Ethernet client connections
Table 3-11: Case A
Table 3-12: Case B
Table 3-13: Case C
Table 3-14: Case D
Table 3-15: Case E
Settings Ethernet
DNP CHANNEL 1 PORT NONE
DNP CHANNEL 2 PORT NONE
104 GENERAL FUNCTION DISABLE
Client 1 Client 2 Client 3
MODBUS NOTHING NOTHING
MODBUS MODBUS NOTHING
MODBUS MODBUS MODBUS
Settings Ethernet
DNP CHANNEL 1 PORT TCP
DNP CHANNEL 2 PORT NONE
104 GENERAL FUNCTION DISABLE
Client 1 Client 2 Client 3
DNP NOTHING NOTHING
DNP MODBUS NOTHING
DNP MODBUS MODBUS
Settings Ethernet
DNP CHANNEL 1 PORT UDP
DNP CHANNEL 2 PORT NONE
104 GENERAL FUNCTION DISABLE
Client 1 Client 2 Client 3 Client 4
DNP NOTHING NOTHING NOTHING
DNP MODBUS NOTHING NOTHING
DNP MODBUS MODBUS NOTHING
DNP MODBUS MODBUS MODBUS
Settings Ethernet
DNP CHANNEL 1 PORT TCP
DNP CHANNEL 2 PORT TCP
104 GENERAL FUNCTION DISABLE
Client 1 Client 2 Client 3
DNP DNP NOTHING
DNP DNP MODBUS
Settings Ethernet
DNP CHANNEL 1 PORT TCP
DNP CHANNEL 2 PORT UDP
104 GENERAL FUNCTION DISABLE
Client 1 Client 2 Client 3 Client 4
