A–60 3 SERIES PROTECTIVE RELAY PLATFORM – COMMUNICATIONS GUIDE
PIXIT
PIXIT for Data set model
PIXIT for Substitution model
PIXIT for Setting group control model
ID Ed Description Value / Clarification
Ds1 1 What is the maximum number of data elements in one
data set (compare ICD setting)
64
Ds2 1 How many persistent data sets can be created by one or
more clients
(this number includes predefined datasets)
NOT SUPPORTED
Ds3 1 How many non-persistent data sets can be created by one
or more clients
NOT SUPPORTED
ID Ed Description Value / Clarification
Sb1 1 Are substituted values stored in volatile memory NOT SUPPORTED
ID Ed Description Value / Clarification
Sg1 1 What is the number of supported setting groups for each
logical device
NOT SUPPORTED
Sg2 1,2 What is the effect of when and how the non-volatile
storage is updated
(compare IEC 61850-8-1 $16.2.4)
NOT SUPPORTED
Sg3 1 Can multiple clients edit the same setting group NOT SUPPORTED
Sg4 1 What happens if the association is lost while editing a
setting group
NOT SUPPORTED
Sg5 1 Is EditSG value 0 allowed NOT SUPPORTED
Sg6 2 When ResvTms is not present how long is an edit setting
group locked
NOT SUPPORTED
