CHAPTER 6: ACTUAL VALUES
6.3.2 Temperature
PATH: ACTUAL VALUES ZV A2 METERING DATA ZV TEMPERATURE
The current level of the 12 RTDs is displayed here. If the RTD is not connected, the value will
be “No RTD”. The values will reflect the RTD names as programmed. The HOTTEST STATOR
RTD
value is shown only if at least one RTD is set as “Stator”.
If no RTDs are programmed in
S8 RTD TEMPERATURE, the THIS FEATURE NOT
PROGRAMMED
flash message will appear when an attempt is made to enter this group of
messages.

TEMPERATURE [
Z]
HOTTEST STATOR
RTD
RTD#1: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #1
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #2
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #3
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #4
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted).
MESSAGE
RTD #5
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted).
MESSAGE
RTD #6
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #7
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted).
MESSAGE
RTD #8
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #9
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #10
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #11
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
MESSAGE
RTD #12
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---
- (shorted)
