Page #7 background image
Structure Mechanism and Installation
Structure Mechanism and Installation
5
Installation procedure:
1) Remove the sticker from the front panel.
2) Put the unit into the installation hole.
When installing the unit, it should be slanted down to the back to
avoid the enlargement of noise or vibration. (Slant between 6-10mm.)
(Shown at right figure.)
The installation place should be strong enough to avoid the
enlargement of noise or vibration.
3) Fill up sews in the cabinet with sponge or foam.
Installation assistance:
Use iron support
The installation hole should be strong
enough to support the air conditioner.
If it cannot, iron support has to be used
outdoors.
Iron support should be fixed on the
building (Shown at right figure.)
Use sunshade board
Air conditioner should avoid anything to
be dropped into it and avoid direct
sunshine. If there is no cover on it, you
should contact the seller for installing
the sunshade board. When installing the
sunshade board, don't let it block the air
inlet at the side grille.
Horizontal line
6~10mm
Sunshade board
Wall
Wooden frame
Rubber plate
Support
Horizontal line
6~10mm
