Terminal locations - Unit Sizes 62/64
Illustration 5.24: Terminal locations - Inverter Cabinet - 62 and 64 (front, left and right side view)
1) Ground bar
Terminal locations - Rectifier (Unit Sizes 61, 62, 63 and 64)
Illustration 5.25: Terminal locations - Rectifier (Left side, front and right side view)
1) Loadshare Terminal (-)
2) Ground bar
3) Loadshare Terminal (+)
AF-600 FP High Power Operating Instructions
58
5
