Disconnect and
Plug here
Outlet Fitting Assembly for UFC 207, UF 207, UFC 209,
UF 209, UFC 211 and UF 211 Series models installed
in standard conguration shown. Other models and
Systems equipped with the Surface Water Option Kit
have different Outlet Fitting Assemblies.
For you will need:
Cap Wrench
Adjustable wrench
Nut driver
For the
, you will need:
4 US gallons (16 litres) plumbers antifreeze that is-
and rated for -58
o
F (-50
o
C).
2 - ¾” MNPT PVC plug
For the
, you will need:
3 US gallons (12 litres) plumbers antifreeze that is-
and rated for -58
o
F (-50
o
C).
1- ¾” MNPT PVC plug
1 - ½” MNPT PVC plug
1
Close the Inlet Valve. Completely drain the System
and household piping. To drain the System, refer to the
section under
on how to perform a Manual Flush. To
drain the household pipes, open a cold water tap (on the
lowest level of the home) and leave until the tap only drips.
Turn off the tap when the pipes are drained.
3
Drain the ltered water from the System by
disconnecting the Outlet Stainless Steel Flex Hose where
it connects to the home plumbing, and drain into a large
bucket. Plug the Flex Hose and System by installing a ¾”
MNPT PVC plug.
4
If an External Prelter has been installed, open the
Mini Ball Valve on the bottom of the housing and allow
to drain. Press the red button on the External Prelter
head to speed up draining. Unscrew the housing from
the head and remove the External Prefilter cartridge
from the housing, and discard. Do not install a new
lter cartridge. Re-attach the lter housing to the head.
2
Remove the drain hose and Nylon Elbow from the
Drain Solenoid Valve and install a ½” MNPT or ¾” MNPT
PVC plug (depending on the size of the port) into the Drain
Solenoid Valve.
Never use AUTOMOTIVE type antifreezes when
winterizing the System. This may result in serious
injury or death.
Only plumbing antifreeze, consisting primarily of
with no ethanol or other alcohols,
rated for -58
o
F (-50
o
C), may be used to winterize the
System. The use of less-expensive ‘non-propylene glycol
based’ plumbing or RV antifreezes may damage the
System’s internal components .
This may also result in serious injury or death.
Plumbing antifreeze containing will
provide protection of the System against freezing to
-40
o
F (-40
o
C) as long as the proportion of antifreeze
to water is correct. This procedure only protects
the System from freezing and does not protect the
rest of the household water distribution system.
based antifreeze is available at
most hardware stores.
WARNING!
All valves
closed
25
