3.4.1 Cable Lengths
Maximum cable lengths from the CPU to the last device attached to the cable are:
Port 1 (RS-232):
Baud Rate
Maximum Cable Length
19.2 K and below 15 meters (50 ft.)
38.4K 7.5 meters (25 ft.)
57.6K 5 meters (16 ft.)
115.2K 2.5 meters (8 ft.)
Port 2 (RS-485): 1200 meters (4000 ft.)
3.4.2 Serial Port Baud Rates
Port 1 Port 2
RTU protocol 1200, 2400, 4800, 9600,
19.2K, 38.4K
†
, 57.6K
†
1200, 2400, 4800, 9600,
19.2K, 38.4K
†
, 57.6K
†
Serial I/O protocol 1200, 2400, 4800, 9600,
19.2K, 38.4K
†
, 57.6K
†
1200, 2400, 4800, 9600,
19.2K, 38.4K
†
, 57.6K
†
SNP protocol 4800, 9600, 19.2K,
38.4K
†
4800, 9600, 19.2K,
38.4K
†
Local Station Manager (this is
independent of serial protocol
baud rate)
1200, 2400, 4800, 9600,
19.2K, 38.4K, 57.6K,
115.2K
NA
Firmware Upgrade via
WinLoader
2400, 4800, 9600, 19.2K,
38.4K, 57.6K, 115.2K
NA
†
Only on one port at a time.
Some versions of VersaPro software allow configuration of RTU and Serial I/O at 115.2K
baud. However, this baud rate is not supported by the CPU. If a configuration using this
baud rate is stored to the PLC:
1. For RTU, an Unsupported Feature in Configuration fault is logged and the PLC
transitions to Stop Faulted mode.
2. For Serial I/O, the same fault is logged when the transition to Run mode occurs. The
PLC will immediately transition to Stop Faulted mode.
44 GFK-1503E VersaMax PLC User Manual
