Archiving
484 Vivid S5/Vivid S6 User Manual
R2424458-100 Rev. 2
9. Insert the media (CD/DVD or MOD) containing the LATEST
database backup from the Vivid 3 or Vivid 4, into the
Vivid S5/Vivid S6 system.
10. Select the appropriate import path from the drop-down
menu (see FIG).
Figure 9-66: Config menu - Import Data from Removable Media
11. Click Import Vivid-3 Database to commence the import
process.
A progress bar is displayed. The import process may take
some time, depending on the size of the database being.
When the import process is complete, an "Import
Complete" message is displayed. The Import Vivid-3
Database button is disabled (appears grayed-out) and the
Vivid 3/Vivid 4 Database Import option is no longer
available.
12. Repeat steps 3 and 5 above for the Local Archive + Int.
HD dataflow.
Note: The user is now able to review the imported data on the
Vivid S5/Vivid S6 system. The images may be loaded at a later
stage in the normal review process, as described in this
manual.
Exporting the Excel database
It is possible to convert all of the patients' demographic data
and exam measurements to Excel format, which may be
exported to removable media and viewed on a PC. This
procedure is performed from the Admin dialog box.
1. Log in as an Administrator.
2. Press Config, then select Admin.
The Admin dialog window is displayed (see Figure 9-65).
3. Select the V3\V4 DB Import tab.
4. Insert blank media into the appropriate media drive on the
Vivid S5/Vivid S6 system.
5. Click Generate Excel Database (see Figure 9-67).
