GE HEALTHCAREDRAFT VOLUSON® P8 / VOLUSON® P6
DIRECTION 5459672-100, R
EVISION 6 DRAFT (JANUARY 17, 2013) PROPRIETARY SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-35
Section 5-7
Monitor
• Menu key [OSD](Press the OSD (middle) key of the monitor controls over 10 sec.):
This button will enable the On Screen Display to modify the settings and control the special
features. To select a tab use the [LEFT] and [RIGHT] button and then press the OSD button again.
• Decrease < [LEFT]:
Use this button to move down the OSD selection menu and adjust the attribute of the monitor while
in OSD mode. Pressing this button out of the OSD menu allows you to decrease the level of
brightness/contrast of the display screen.
• Increase > [RIGHT]:
Use this button to move up the OSD selection menu and adjust the attribute of the monitor while in
OSD mode. Pressing this button out of the OSD menu allows you to increase the level of
brightness/contrast of the display screen.
NOTE: All changed values will only be saved by selecting “Exit” from the OSD.
If not, the adjusted values will be lost after loss of power.
For further details refer to: Section 6-3 "LCD Monitor Adjustment" on page 6-2.
Figure 5-15 Monitor Adjustment buttons
OSD
Menu key
< left
decrease
right >
increase
On screen Display (OSD)
Keyboard Keys
