Gemini X3 Service Manual

Page 15
39
40 080-085 4 LED (RED) 5φ
41 080-110 1 LED (YELLOW) 5φ
42 080-086 3 LED (GREEN) 5φ
43
44 071-220 2 ROTARY VR 10KA L:15MM
45 081-023 1 SLIDE SWITCH 2P2C UL
46 081-030 1 SLIDE SWITCH
47 081-041 1 SLIDE SWITCH
48 083-099 1 POWER SWITCH
49
50 001-613 1 DC FAN 24V (80×80×25mm)
51 092-078 2
76 061-112 2 METAL FILM RESISTORS 1/
4W 86.6KΩ 1%
77 061-108 2 METAL FILM RESISTORS 1/
4W 1MΩ 1%
78 061-106 2 METAL FILM RESISTORS 1/
4W 2.21KΩ 1%
79
80 060-218 4 CARBON FILM RESISTORS
1/4W 10Ω
81 060-237 2 CARBON FILM RESISTORS
1/4W 62Ω
82 060-245 6 CARBON FILM RESISTORS
1/4W 130Ω
83 060-253 2 CARBON FILM RESISTORS
1/4W 300Ω
84 060-259 8 CARBON FILM RESISTORS
1/4W 510 Ω
85
86 060-279 4 CARBON FILM RESISTORS
1/4W 2.2KΩ
87 060-289 3 CARBON FILM RESISTORS
1/4W 5.6KΩ
88 060-300 5 CARBON FILM RESISTORS
1/4W 16KΩ
89 060-306 9 CARBON FILM RESISTORS
1/4W 30KΩ
90 060-315 5 CARBON FILM RESISTORS
1/4W 68KΩ
91
92 050-153 2 ELECTROLYTIC
CAPACITORS N.P 10µ/50V
93 050-197 1 ELECTROLYTIC
CAPACITORS N.P 100µ/10V
94 050-049 2 ELECTROLYTIC
CAPACITORS 100µ/16V
95 050-120 1 ELECTROLYTIC
CAPACITORS 220µ/25V
96 050-058 2 ELECTROLYTIC
CAPACITORS 220µ/16V
97 050-200 2 ELECTROLYTIC
CAPACITORS 6800µ/80V
98
99 051-148 2 CERAMIC CAPACITOR
0.01µ/500V
100 051-018 4 CERAMIC CAPACITOR 22P/
50V
101 051-024 2 CERAMIC CAPACITOR 39 /
50V
