Gigabyte B360 HD3P User Manual

Storage Interface  Chipset:
- 6 x SATA 6Gb/s connectors
* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
 Intel
®
Optane
™
Memory Ready
* System Acceleration with Intel
®
Optane
™
Memory enabled on the M2A_32G connector
only.
USB  Chipset:
- 1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
* The F_USB2 connector shares bandwidth with the CNVi connector. It becomes
unavailable when a Wi-Fi module is populated in the CNVi connector.
Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 3 x system fan headers
 2 x digital LED strip headers
 2 x digital LED strip power select jumpers
 2 x RGB (RGBW) LED strip headers
 6 x SATA 6Gb/s connectors
 2 x M.2 Socket 3 connectors
 1 x front panel header
 1 x front panel audio header
 1 x S/PDIF Out header
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1 x Thunderbolt
™
add-in card connector
 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
 1 x parallel port header
 1 x serial port header
 1 x Clear CMOS jumper
Back Panel
Connectors
 1 x PS/2 keyboard/mouse port
 1 x DVI-D port
 1 x HDMI port
 1 x USB 3.1 Gen 2 Type-A port (red)
 1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
 2 x USB 3.1 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1 x RJ-45 port
 6 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
- 7 -

Gigabyte B360 HD3P Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Supported memory module capacities	16GB
Component for	PC
Motherboard chipset	Intel® B360
Audio output channels	7.1 channels
Motherboard form factor	ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Ethernet interface type	Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	16 Mbit
Supported storage drive types	HDD & SSD
PCI Express x16 slots	3
Number of M.2 (M) slots	2
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	225 mm
Width	305 mm
