Gigabyte GA-945PL-S3 User Manual

Hardware Installation- 15 -
English
Dual Channel Memory Configuration
GA-945PL-DS3/GA-945PL-S3 supports the Dual Channel Technology. After
operating the Dual Channel Technology, the bandwidth of Memory Bus will
add double.
GA-945PL-DS3/GA-945PL-S3 includes 4 DIMM sockets, and each Channel has two DIMM sockets as
following:
Channel 0 : DDRII1, DDRII2
Channel 1 : DDRII3, DDRII4
If you want to operate the Dual Channel Technology, please note the following explanations due
to the limitation of Intel chipset specifications.
1. Dual Channel mode will not be enabled if only one/three DDRII memory module is
installed.
2. To enable Dual Channel mode with two or four memory modules (it is recommended to
use memory modules of identical brand, size, chips, and speed), install the memory
according to the dual channel memory configuration table below (Figure 1).
Memory configurations in Figure 2 will result in memory frequency being reduced from 533MHz down
to 400MHz. (DS: Double Side, SS: Single Side, X: Empty)
Figure 1
2 memory modules
4 memory modules
DDRII1 DDRII2 DDRII3 DDRII4
DS/SS X DS/SS X
DS/SS X X DS/SS
X DS/SS DS/SS X
X DS/SS X DS/SS
SS SS SS SS
Dual Channel Memory Configuration Table (DS: Double Side, SS: Single Side, X: Empty)
Figure 2
2 memory modules
3 memory modules
4 memory modules
DDRII1 DDRII2 DDRII3 DDRII4
SS SS X X
XXSSSS
SS SS DS/SS X
SS SS X DS/SS
DS/SS X SS SS
X DS/SS SS SS
SS SS SS SS
Because of chipset limitations, do not populate both DIMM sockets of the same channel with
double-sided memory modules to prevent system's failure to start or incorrect detection of
memory modules,

Gigabyte GA-945PL-S3 Specifications

General

Number of memory slots	4
Maximum internal memory	2 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	2
S/PDIF out connector	Yes
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Motherboard form factor	ATX
LAN controller	Realtek RTL8111B
Networking features	Gigabit Ethernet

Weight and Dimensions

Depth	190 mm
Width	305 mm
