Gigabyte GA-P61A-D3 User Manual

- 32 -
Execute Disable Bit &
(Note)
Enables or disables Intel Execute Disable Bit function. This function may enhance protection for the computer,
reducing exposure to viruses and malicious buffer overow attacks when working with its supporting software
and system. (Default: Enabled)
Intel Virtualization Technology &
(Note)
Enables or disables Intel Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology
will allow a platform to run multiple operating systems and applications in independent partitions. With
virtualization, one computer system can function as multiple virtual systems. (Default: Disabled)
VT-d &
(Note)
Enables or disables Intel Virtualization Technology for Directed I/O. (Default: Enabled)
Administrator Password &
Allows you to congure an administrator password. Press <Enter> on this item, type the password, and
then press <Enter>. You will be requested to conrm the password. Type the password again and press
<Enter>. You must enter the administrator password (or user password) at system startup and when entering
BIOS Setup. Differing from the user password, the administrator password allows you to make changes to
all BIOS settings.
User Password &
Allows you to congure a user password. Press <Enter> on this item, type the password, and then press
<Enter>. You will be requested to conrm the password. Type the password again and press <Enter>. You
must enter the administrator password (or user password) at system startup and when entering BIOS Setup.
However, the user password only allows you to make changes to certain BIOS settings but not all.
To cancel the password, press <Enter> on the password item and when requested for the password, enter the
correct one rst. When prompted for a new password, press <Enter> without entering any password. Press
<Enter> again when prompted to conrm.
(Note) This item is present only when you install a CPU that supports this feature. For more information about
Intel CPUs' unique features, please visit Intel's website.
2-6 Peripherals

Gigabyte GA-P61A-D3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Number of SATA II connectors	4
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC887
Component for	PC
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	Not supported
PCI slots	3
Controller interface type	iTE IT8728
Bundled software	Norton Internet Security OEM
LAN controller	Atheros AR8151
Networking features	Gigabit Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	190 mm
Width	305 mm
