Press down on the rear fender, separate the
folding hook and fender buckle, then lift the tiller
upright (as shown in the gure). Once the scooter
is locked in the upright position, verify by gently
trying to fold.
Place the console into the top of the tiller.
TOOLS YOU’LL NEED: 4 mm Allen Key Wrench (included).
Take the cord that is attached to the hook and
bring it to the front of the tiller. Pull the handbrake
towards you and insert the round metal piece into
the opening. String the small silver cord through
the solid piece of the handbrake. Make sure the
metal piece on the red cord is pushed fully into
the handbrake.
Use an Allen wrench to loosen the screws located
at the hook and detach. Once you’ve removed the
hook and screws, make sure to remove the cover
from the top of the tiller.
Assemble Your Scooter
1
4
2
3
To Next Page
