Outdoor Unit Model
3VIR24HP230V1AO
Outdoor Unit Product Code CB385W02600
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD
Compressor Model QXFS-B181zX030AA
Compressor Oil FW68DA
Compressor Type Twin Rotary
Compressor LRA. A 25
Compressor RLA A 10.68
Compressor Power Input W 1610
Compressor Overload Protector HPC115/95U1 KSD115
℃
Throttling Method Electron expansion valve
Set Temperature Range ºF 61~86
Cooling Operation Ambient Temperature Range ºF -20~122
Heating Operation Ambient Temperature Range ºF -22~86
Condenser Form Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94
Condenser Rows-n Gap mm 2-Φ8
Condenser Coil Length (LXDXW) mm 952×38.1×748
Fan Motor Speed rpm 800
Fan Motor Power Output W 90
Fan Motor RLA A 0.7
Fan Motor Capacitor μF /
Outdoor Unit Air Flow Volume CFM 2354
Fan Type Axial-ow
Fan Diameter mm Φ550
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 59/-/-
Sound Power Level (H/M/L) dB (A) 69/-/-
Dimension(WXHXD) inch 39 31/64 X 31 7/64 X 16 52/64
Dimension of Carton Box (LXWXH) inch 42 33/64 X 19 6/64 X 33 5/64
Dimension of Package(LXWXH) inch 42 41/64 X 19 14/64 X 33 42/64
Net Weight Ib 124.6
Gross Weight Ib 135.6
Refrigerant R410A
Refrigerant Charge oz 63.5
Connection
Pipe
Connection Pipe Length ft 24.6
Connection Pipe Gas Additional Charge oz/ft 0.5
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 5/8
Max Distance Height ft 65.6
Max Distance Length ft 98.4
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice. Please refer to the nameplate of the unit.
