18
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Compressor
Compressor Manufacturer/Trademark
ZHUHAI LANDA COMPRESSOR
CO., LTD
ZHUHAI LANDA COMPRESSOR
CO., LTD
Compressor Model QXD-B172A030A QXD-B222A030
Compressor Oil 5GSD-TB or equivalent 5GSD-TB or equivalent
Compressor Type Rotary Rotary
L.R.A. A 21.5 26
Compressor RLA A 3.4 4.5
Compressor Power Input W 770 1000
Overload Protector HPA-022 HPA-030
Evaporator
Fan Type Centrifugal Centrifugal
Diameter Length(DXL) mm Φ204.6X72 Φ204.6X72
Cooling Speed(H/M/L) rpm 1000/860/730 1000/860/730
Heating Speed(H/M/L) W 1000/860/730 1000/860/730
Fan Motor RLA A 0.29 0.29
Fan Motor Capacitor μF 2.5 2.5
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ7 Φ7
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 591X25.4X228.6 591X25.4X228.6
Swing Motor Model / /
Output of Swing Motor W / /
Condenser
Fan Type Centrifugal Centrifugal
Fan Diameter mm Φ224.5X80 Φ224.5X80
Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Φ5 Φ5
Rows-n Gap mm 3-1.3 + 1-1.4 2-1.3 + 1-1.4
Coil Length (LXDXW) mm 592X34.2X304.8/475X11.4X266.7 576X22.8X304.8/ 475X11.4X266.7
Fan Motor Speed rpm 980/800 980/800
Output of Fan Motor W 50 50
Fan Motor RLA A 0.5 0.5
Fan Motor Capacitor μF 2.5 2.5
To Next Page
