14
Technical Information
Service Manual
Outdoor Unit
Model of Outdoor Unit GWH12NC-K3NNC7F/O
Product Code of Outdoor Unit CA195W06400
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD
Compressor Model QXA-B120C150
Compressor Oil RB68EP
Compressor Type Rotary
L.R.A. A 22
Compressor RLA A 4.7
Compressor Power Input W 1020
Overload Protector INTERNAL
Throttling Method Capillary
Operation Temp
o
C 16~30
Ambient Temp (Cooling)
o
C 18~43
Ambient Temp (Heating)
o
C -7~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Rows-n Gap mm 1-1.4
Coil Length (LXDXW) mm 721.5X12.7X495
Fan Motor Speed rpm 850
Output of Fan Motor W 35
Fan Motor RLA A 0.33
Fan Motor Capacitor μF 2.5
Air Flow Volume of Outdoor Unit m
3
/h 1600
Fan Type Axial-o
Fan Diameter mm Φ395
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 52/-/-
Sound Power Level (H/M/L) dB (A) 62/-/-
Dimension (WXHXD) mm 776X540X320
Dimension of Carton Box (LXWXH) mm 820X355X580
Dimension of Package (LXWXH) mm 823X358X595
Net Weight kg 29
Gross Weight kg 31.5
Refrigerant R410A
Refrigerant Charge kg 0.8
Connection
Pipe
Length m 5
Gas Additional Charge g/m 20
Outer Diameter Liquid Pipe mm Φ6
Outer Diameter Gas Pipe mm Φ9.52
Max Distance Height m 10
Max Distance Length m 20
Note: The connection pipe applies metric diameter.
The above data is subject to change without notice; please refer to the nameplate of the unit.
