62
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH12MA-K3DNB3L/I
Product Code CB163N07100
1 Front Panel Sub-Assy 2001227802 1
2 Front Panel 20012201S 1
3 Filter Sub-Assy 11122081 2
4 Screw Cover 24252016 3
5 Electric Box Cover2 20122075 1
6 Front Case 20012179C 1
7 Axile Bush 10542036 1
8 Guide Louver 10512111 1
9 Air Louver 1 10512113 1
10 Air Louver 2 10512114 1
11 Helicoid Tongue 26112162 1
12 Axile Bush 10542036 1
13 Rear Case assy 2220210111 1
14 Cross Flow Fan 10352043 1
15 Fan Bearing 76512203 1
16 O-Gasket sub-assy of Bearing 7651205102 1
17 O-Gasket of Cross Fan Bearing 76512203 1
18 Ring of Bearing 26152022 1
19 Remote Controller 30510065 1
20 Drainage Hose 0523001406 1
21 Wall Mounting Frame 01252015 1
22 Evaporator Assy 0100276201 1
23 Evaporator Support 24212090 1
24 Connecting Cable 4002052317 0
25 Connecting Cable 400205403 0
26 Decorative Strip / /
27 Tube Sensor 3900031302 1
28 Ambient Temperature Sensor / /
29 Main Board 30138000723 1
30 Terminal Board 42011233 1
31 Electric Box 2011208201 1
32 Transformer / /
33 Electric Box Assy 10000202446 1
34 Display Board 30565037 1
35 Crank 10582070 1
36 Step Motor 1521212901 1
37 Rubber Plug (Water Tray) 76712012 1
38 Motor Press Plate 26112160 1
39 Fan Motor 15012115 1
40 Pipe Clamp 26112164 1
41 Jumper 4202021902 1
42 Capacitor CBB61 33010747 1
43 Shield Cover of Electric Box Sub-assy 0159207301 1
44 Shield Cover of Electric Box 0141203601 1
45 Electric Box Cover1 22242135 1
46 Power Cord / /
To Next Page
