GWH12MA-K3DNA3L/O
Product Code CB171W10300
1 Left Side Plate 01303200P 1
2 Fan Motor 15013085 1
3 Motor Support 01703136 1
4 Condenser Assy 01100200426 1
5 Top Cover Sub-Assy 01253081 1
6 Rear Grill 01475014 1
7 Clapboard Sub-Assy 01233180 1
8 Compressor and Fittings 0010389201 1
9 Compressor Gasket 76713027 3
10 4-Way Valve Assy 03073386 1
11 Big Handle 2623343106 1
12 Cut off Valve Assy 0713380601 1
13 Cut off Valve Assy 071302392 1
14 Valve Support
01713142P
1
15 Front Grill 22413044 1
16 Cabinet 01433033P 1
17 Axial Flow Fan 10333011 1
18 Chassis Sub-assy 01700000033P 1
19 Electric Box Assy 10000100353 1
20 Electric Box 20113032 1
21 Main Board 30138000745 1
22 Reactor 43130184 1
23 Wire Clamp 71010103 1
24 Terminal Board 42010313 1
